Introducing Kirin Laser’s split-type mini laser marking machine, offering versatile power options of 20W, 30W, 50W, 60W, and 100W to suit your specific marking needs. This compact yet powerful machine is designed to mark a wide range of materials, including all types of metals, as well as ABS and PVC plastics.
The design separates the workbench from the laser source, providing a spacious work platform for handling various materials and sizes. This unique split configuration allows for better maneuverability and convenience during operation. The laser head can be easily extended out from its compartment, simplifying routine inspections and maintenance tasks.
MODEL | KR-SF20 | KR-SF30 | KR-SF50 | KR-SF60 | KR-SF100 |
laser Power | 20W | 30W | 50W | 60W | 100W |
Operating voltage | 110V/220V, 50/60Hz | 110V/220V, 50/60Hz | 110V/220V, 50/60Hz | 110V/220V, 50/60Hz | 110V/220V, 50/60Hz |
Laser Source | JPT/RAYCUS/MAX | JPT/RAYCUS/MAX | JPT/RAYCUS/MAX | JPT/RAYCUS/MAX | JPT/RAYCUS/MAX |
Galvo Head | ZBTK/Sino-galvo | ZBTK/Sino-galvo | ZBTK/Sino-galvo | ZBTK/Sino-galvo | ZBTK/Sino-galvo |
Marking Area | 110mm*110mm | 110mm*110mm | 110mm*110mm | 110mm*110mm | 110mm*110mm |
Power Adjustment Range(%) | 0-100% | 0-100% | 0-100% | 0-100% | 0-100% |
Marking Speed | 0-1000mm/s | 0-1000mm/s | 0-1000mm/s | 0-1000mm/s | 0-1000mm/s |
Fiber Cable Length | 3m | 3m | 3m | 3m | 3m |
Laser Wavelength | 1064nm | 1064nm | 1064nm | 1064nm | 1064nm |
System Software | EZCAD2 | EZCAD2 | EZCAD2 | EZCAD2 | EZCAD2 |
Cooling Method | Air-cooled | Air-cooled | Air-cooled | Air-cooled | Air-cooled |
Machine Dimensions | 700mm*500mm *550mm | 700mm*500mm *550mm | 700mm*500mm *550mm | 700mm*500mm *550mm | 700mm*500mm *550mm |
Machine Weight | About 46Kg | About 46Kg | About 55Kg | About 60Kg | About 72Kg |
The Sino-galvo Head in Kirin Laser machines features a high-speed scanning motor imported from the United States. This galvo head is known for its compact size, rapid speed, and exceptional precision, delivering highly stable and reliable performance in various marking applications.
With excellent operational stability, the Sino-galvo head ensures high positioning accuracy and swift marking speeds. It also offers robust anti-interference capabilities, making it ideal for environments where precision and consistency are crucial.
The split-type design of Kirin Laser’s mini laser marking machine offers a unique configuration where the workbench and laser are separated, providing a more extensive and versatile work platform for a variety of marking tasks.
Thanks to its lightweight build, this machine is easy to transport across different work locations, ensuring flexibility and convenience for your marking needs.
Additionally, the laser can be independently pulled out from the main cabinet, simplifying inspection and maintenance processes whenever required, enhancing operational efficiency and reducing downtime.
Kirin Laser’s machines are equipped with a reliable emergency stop button designed to instantly cut off power in case of emergencies. This feature provides an added layer of safety for both operators and the equipment, ensuring quick response to any unexpected situations.
The integrated voltage indicator allows continuous monitoring of the voltage levels, aiding in the detection of potential electrical issues early on. This feature helps prevent equipment damage and ensures smooth and safe operation. With these safety-focused features, Kirin Laser machines offer a secure working environment, prioritizing operator safety and equipment longevity.
To illustrate the advantages of the auto-focus function, let’s take Kirin Laser’s 30W split-type fiber laser marking machine, model KR-SF30, as an example. This advanced laser marking machine features an auto-focus function, positioning it as one of the most efficient and user-friendly laser marking devices available in the market today. The system is designed for simplicity, allowing users to mark various materials quickly and accurately within seconds.
Versatility in Material Compatibility and Thickness Adjustment
The 30W Fiber Laser Marking Machine is engineered to handle a broad range of materials, including metals like stainless steel, aluminum, and brass, as well as certain plastics. It comes equipped with an adjustable focus mode, making it capable of marking items of varying thicknesses with ease, accommodating a wide array of engraving tasks. With the robust capabilities of this machine, users can confidently work through even the most challenging materials without sacrificing precision.
User-Friendly Automatic Focus Adjustment
One of the standout features of the KR-SF30 is its automatic focus adjustment, which enhances usability significantly. By enabling automatic focus, users simply need to adjust the laser beam’s power output to match the specific requirements of the material being marked. This functionality ensures that the machine can perform consistently across different applications, providing reliable results no matter the type of material.
Ideal for Small Businesses, Designers, and Manufacturers
The KR-SF30 is tailored for small businesses, designers, and manufacturers who prioritize precision and quality in their marking processes. With this advanced tool, businesses can enhance their products’ visual appeal and branding, helping them stand out in a competitive market. Contact us today to learn how the KR-SF30 can elevate your product offerings and capture the attention of potential customers.
Fiber Laser Machine Compatibility
The Kirin Laser Fiber Laser Marking Machine is highly versatile, compatible with multiple image formats like .plt and .dxf, making it an excellent solution for any business needing to mark products with serial numbers, logos, or other detailed information. Designed to integrate smoothly with most Windows-based systems, this laser marking machine offers a wide range of applications and is perfect for both newcomers and experienced users due to its easy setup and straightforward operation.
Advanced Laser Source
Equipped with a 30W fiber laser source, this machine is a robust and dependable industrial-grade marking system known for its impressive throughput and consistent performance. Unlike other marking systems, the Kirin Laser Fiber Laser Marking Machine produces no hazardous gases, making it safe for the environment and eliminating the risk of fire. This versatile laser can mark various materials, including metal, wood, and plastic, without causing any damage to the surface. It delivers high-quality marks with a refined finish by utilizing short, high-frequency bursts that penetrate deeply into the material for heat-resistant engravings on all types.
This advanced technology allows you to mark almost any material within seconds, including engraving intricate logos on marble flooring, carpets, leather upholstery, or even glass. With the Kirin Laser system, you can create custom designs with precision and elegance according to your specific requirements.
Laser Power and Cost-Efficiency
Operating with a consistent 30W average output, the Kirin Laser Fiber Laser Marking Machine ensures stable performance by generating high-frequency pulses for uniform marking quality without material melting. The laser beam is focused through a lens to create a concentrated line of light, resulting in precise and clear engravings. With this machine, downtime and material waste are minimized, enabling more productivity in less time.
The fiber lasers used in this equipment are highly durable, lasting up to ten times longer than conventional lasers, making them a cost-effective solution for businesses looking to save on consumable costs. This longevity, combined with its ability to handle multiple projects without needing frequent part replacements, makes the Kirin Laser Fiber Laser Marking Machine an excellent investment.
Marking Speeds and Options
Kirin Laser’s Fiber Laser Engraving Machine is designed to offer a variety of engraving options on different materials, including metals, plastics, ceramics, and coated metals. The 30W Fiber Laser Engraving Machine starts its processing time as fast as 1 second, which is faster than many comparable models in its category. With a capacity for 24-hour continuous operation, it stands out for its exceptional durability and efficiency.
The machine’s air-spaced design prevents laser-induced thermal distortion, ensuring cleaner and more accurate marks on sensitive materials. Its efficient air cooling system also helps the machine run cooler, reducing wear and tear, and enhancing its overall performance. Whether you’re engraving intricate logos or creating custom designs, the Kirin Laser system allows you to do so quickly and without the need for extensive design experience.
Durability
This 30W fiber laser engraver is designed for industrial-grade durability, providing precise engraving capabilities without causing any warping or delamination on plastic sheets and metals. Built with a high-strength fiber laser head, the machine delivers fast and reliable results, making it an excellent choice for businesses that demand consistent quality. Its intuitive interface further simplifies operation, ensuring ease of use for all operators.
If you’re looking for a laser marking machine built to last, the Kirin Laser 30W Fiber Laser Marking Machine is an ideal choice, designed to provide outstanding performance and longevity.
Warranty
Kirin Laser offers a 2-year warranty and lifetime technical support for this product, ensuring that your investment is well protected and cared for. With a total cost starting at approximately $3,500, you can be confident in your purchase, knowing that a team of experts is available to help you maximize the potential of your new laser marking machine. Let your creativity shine with Kirin Laser’s reliable and versatile technology!
The 30W fiber laser engraver is ideal for marking a wide range of metal materials. The power output can be adjusted to etch intricate designs or text on metal surfaces, including stainless steel and aluminum. Additionally, it can engrave certain plastics like ABS plastic with precision. However, it's important to note that a 30W fiber laser is not suitable for most non-metal materials, such as wood, paper, leather, and cloth. These materials typically require different laser types for effective marking and engraving.
Fiber lasers are known for their durability and long operational life. They can be used continuously for several hours before needing a short cooling period. After cooling, the laser is ready to operate at full power again within minutes. The theoretical lifespan of a fiber laser source can reach up to 100,000 hours. For more insights into the performance and longevity of our fiber lasers, check customer reviews and feedback.
CO2 lasers are gas-based lasers with a typical lifespan ranging from 2,000 to 20,000 hours. They are primarily used for engraving a variety of non-metal materials such as wood, leather, plastic, and acrylic. On the other hand, fiber lasers utilize advanced optical fiber technology, offering a longer working life and exceptional versatility. Fiber lasers are specifically designed for engraving all types of metal materials and are ready to handle a wide array of marking tasks without requiring costly upgrades or modifications.
No, the 30W fiber laser marking machine operates without the need for gas. It uses photoelectric conversion to engrave on metal surfaces without any additional gas sources. This not only reduces operational costs but also ensures a clean working environment, free from the risk of gas contamination. The system's adjustable output settings also prevent damage to delicate materials, offering users greater control over their engraving tasks.
The packaging for our 30W fiber laser engraver is designed with utmost care to ensure safe transportation. We use a 3-layered packaging system: the outer layer is a sturdy plywood case; the middle layer is foam that cushions the entire equipment; and the innermost layer is a thick plastic bag that provides waterproof protection. These measures minimize the risk of damage during transit. Our shipping agents have extensive experience in handling such sensitive equipment. You can contact us to view a sample picture of the packaging.
Typically, the production time for the 30W fiber laser engraver is about 7 working days. After production, we ship the machine via air express services like FedEx or TNT. The estimated time of arrival (ETA) is between 4 to 6 working days to your location. For more insights into our delivery process, feel free to check our customer testimonials.
Our team of engineers installs and tests each device thoroughly before shipping. For any additional small parts installation and operating guidance, we provide a detailed training video and a user manual with every purchase. Even new users can easily learn the setup and installation process through these resources.
Kirin Laser offers extensive support after purchase for both hardware and software needs. We provide online assistance in English via Skype, WhatsApp, WeChat, Email, and Video. For remote support, TeamViewer software can be used upon request. In case of hardware issues, our team will help you identify the problem and send replacement parts as needed.
For information regarding free shipping options on our 30W Fiber Laser Engraver, please contact us directly. New customers may also qualify for special vouchers, making the deal even more attractive.
The maintenance required for a fiber laser engraver is minimal compared to other laser types. The fiber laser system is highly durable and doesn't require frequent part replacements. Regular cleaning of the lens and protective glass is recommended to maintain optimal performance. Users should also check the cooling system periodically to ensure it is functioning properly, which helps to prevent overheating and extends the machine's lifespan.
