Flying Laser Marking Machine

The CCD visual positioning flying laser marking machine from Kirin Laser is engineered for precision and efficiency. This machine is equipped with an advanced visual positioning system that accurately identifies the marking area, ensuring flawless and consistent marking on a wide range of products.

With the capability to recognize and mark multiple items simultaneously, this machine significantly boosts marking efficiency and reduces labor costs. Ideal for applications requiring high accuracy and speed, it is a go-to solution for industries where quality and productivity are paramount.

Descriptions

1. Overview: A Flying Laser Marking Machine is specifically designed for high-speed, continuous marking on products moving along a production line. Unlike traditional stationary laser markers, this machine is equipped with a dynamic marking system that ensures precision and clarity even when the product is in motion. It is widely used in various industries such as pharmaceuticals, food & beverage, electronics, and automotive parts for marking barcodes, QR codes, serial numbers, logos, and other necessary information.

2. Key Features:

High Speed and Efficiency: The flying laser marking machine is capable of marking at high speeds up to 7000 mm/s, which allows it to keep up with fast-moving production lines, ensuring no slowdown in the manufacturing process.
Dynamic Focusing Technology: The machine utilizes dynamic focusing technology to ensure that the laser beam remains sharply focused, providing clear and consistent marks on moving products.
Non-Contact Marking: With its non-contact marking capabilities, the machine does not wear down or damage the products being marked. This ensures a longer machine lifespan and minimal maintenance costs.
Versatile Material Compatibility: It is compatible with a wide range of materials, including metals, plastics, ceramics, and more. This versatility makes it a suitable choice for various industries.
User-Friendly Software Integration: Equipped with user-friendly software that integrates easily with existing production line control systems, it simplifies the setup and operation for the users.

3. Applications: Flying laser marking machines are commonly used for marking products in continuous production environments. Key applications include:

Food and Beverage Packaging: Marking expiration dates, batch numbers, and QR codes on bottles, cans, and cartons.
Pharmaceutical Industry: For marking dosage information, barcodes, and serial numbers on medicine packaging.
Electronics and Automotive Parts: Engraving serial numbers, logos, and technical specifications on components and devices.

4. Advantages:

Cost-Effective: Reduces labor costs by automating the marking process.
High Precision: Maintains high precision in marking even at high speeds, ensuring consistent quality.
Low Maintenance: Minimal maintenance required due to the non-contact nature of the marking process.

Parameters

Model	KR-FLY20	KR-FLY30	KR-FLY50	KR-FLY60
Machine size	39808001300mm	39808001300mm	39808001300mm	39808001300mm
Net weight	About 220kg	About 220kg	About 220kg	About 225kg
Working environment	0~35°C humidity≤90%	0~35°C humidity≤90%	0~35°C humidity≤90%	0~35°C humidity≤90%
Cooling system	Air Cooling	Air Cooling	Air Cooling	Air Cooling
Conveyor length	Standard 1.5 meters can be customized	Standard 1.5 meters can be customized	Standard 1.5 meters can be customized	Standard 1.5 meters can be customized
Laser Parameters
Power	20W	30W	50W	60W
Marking area	100100mm-300300mm	100100mm-300300mm	100100mm-300300mm	100100mm-300300mm
Laser wavelength	1064nm	1064nm	1064nm	1064nm
Working voltage	0.5KW/AC220V/50Hz(option)	0.5KW/AC220V/50Hz(option)	0.5KW/AC220V/50Hz(option)	0.5KW/AC220V/50Hz(option)
Lifting pillar	500mm(customize)	500mm(customize)	500mm(customize)	500mm(customize)
Minimum character	0.1mm	0.1mm	0.1mm	0.1mm
Minimum line width	0.01mm	0.01mm	0.01mm	0.01mm
Repeatability accuracy	0.003mm	0.003mm	0.003mm	0.003mm
Resolution	0.001mm	0.001mm	0.001mm	0.001mm
Marking speed	0-7000mm/s	0-7000mm/s	0-7000mm/s	0-7000mm/s
Laser modulation frequency	20kHz~80kHz	20kHz~80kHz	20kHz~80kHz	20kHz~80kHz

Size

More Details

Flying Laser Marking Scanner

Kirin Laser’s advanced rapid area scanning technology is designed to maximize productivity by covering extensive marking zones in record time. This optimized scanning process significantly cuts down on marking cycles, allowing for a dramatic boost in production speed and efficiency.

With high-speed area scanning, Kirin Laser ensures uniform laser power distribution across the entire marking field. This technology effectively eliminates inconsistencies that could arise from varying speeds or repeated passes, ensuring flawless and consistent results in every operation.

High-Precision Vision System

Kirin Laser’s flying laser marking machine is equipped with a high-resolution industrial camera that captures real-time dynamic images of the workpiece. This advanced vision system ensures precise detection of any coordinate shifts of the moving workpiece, maintaining exceptional accuracy throughout the process.

By leveraging high-precision visual inspection, the system identifies defects and positional deviations of the workpiece early on. This proactive approach allows for immediate adjustments or the removal of non-conforming products, effectively reducing scrap rates and minimizing material waste.

Conveyor Belt

Conveyor belts in flying laser marking machines are crucial for high-speed marking on moving products. These systems are widely used in production lines for industries like food and beverage, pharmaceuticals, and electronics. The conveyor belt’s synchronized movement with the laser enables efficient marking of batch numbers, barcodes, and serial numbers on various products.

Key features include adjustable speed settings to align the marking speed with the production line’s pace, ensuring precise marks without interruptions. The belts are built from durable materials, and the system includes sensors to maintain alignment for consistent marking quality.

What Kirin Laser’s Flying Fiber Laser Marking Machines Bring To You?

Kirin Laser’s flying fiber laser marking machines offer significant advantages for various industrial applications, especially in environments requiring high-speed, efficient, and precise marking on production lines.

Key Advantages of Flying Fiber Laser Marking Machines:

High-Speed Marking and Efficiency: Flying fiber laser marking machines are specifically designed for integration with automated production lines, allowing for continuous, high-speed marking without the need to stop or slow down production. This significantly boosts productivity, making them ideal for industries that require rapid and consistent marking of products like electronics, automotive parts, and packaging materials.
Non-Contact and Low-Impact Processing: Unlike traditional methods such as inkjet or pad printing, flying fiber laser marking is a non-contact process. This eliminates the risk of mechanical wear and tear on both the marking equipment and the products being marked. It is especially beneficial for delicate components in the electronics industry, where maintaining the integrity of materials is crucial.
Durable and High-Quality Markings: The laser marking process provides permanent, abrasion-resistant marks that do not fade over time. These marks can withstand harsh environmental conditions, making them suitable for applications in automotive, aerospace, and other industries where durability is a key requirement.
Environmentally Friendly and Cost-Efficient: These machines do not use consumables like ink or chemicals, reducing both operational costs and environmental impact. The air-cooled design and minimal maintenance requirements further contribute to cost savings, making them an economical choice for businesses.
Versatile Applications Across Industries: Flying fiber laser marking machines can handle a wide range of materials, including metals, plastics, ceramics, and more. They are used in various sectors such as food and beverage, pharmaceuticals, electronics, automotive, and consumer goods, where they are employed to mark barcodes, serial numbers, QR codes, logos, and other essential product information.
Ease of Integration and Operation: The compact design of these machines, combined with easy-to-use software and digital controls, allows for straightforward integration into existing production lines. Operators can control the machines via computer or even mobile devices, ensuring flexibility and ease of use .

Application Examples:

Electronics Industry: Flying laser marking machines are ideal for marking small and sensitive electronic components with essential information like QR codes and serial numbers without causing damage. This facilitates better inventory management, quality control, and traceability throughout the product lifecycle.
Automotive and Aerospace: These machines are widely used to mark components that require permanent identification and traceability under extreme conditions, such as parts exposed to high temperatures or corrosive environments.
Food and Beverage Packaging: The machines can rapidly mark production dates, batch numbers, and barcodes on various packaging materials, ensuring compliance with industry standards and enhancing traceability.

How Flying Fiber Laser Marking Machines Work?

Integration with Conveyor Systems: Flying fiber laser marking machines are typically integrated with conveyor belts or automated production lines. The objects to be marked are placed on the conveyor, which then moves them continuously under the laser marking head. The machine’s sensors detect each product’s position, ensuring the laser precisely marks each item at the correct location as it moves through the line.
Laser Source and Control: The machine utilizes a fiber laser source, known for its high efficiency, stability, and long service life. It operates by focusing a high-intensity laser beam onto a small area on the product’s surface. The beam is directed and controlled by a computer using software like EzCad, which allows for adjustments in marking parameters such as speed, power, and marking pattern. The laser etches information like serial numbers, barcodes, logos, or dates onto materials such as metals, plastics, and ceramics.
Continuous Marking at High Speeds: The marking process is continuous and does not require stopping the production line, which greatly enhances productivity. High-speed galvo heads are used to steer the laser beam, allowing for rapid and precise marking. These machines can reach marking speeds of up to 7,000 mm/s, making them ideal for high-volume production environments such as automotive, electronics, packaging, and more.
No Consumables and Low Maintenance: Unlike traditional marking methods, flying fiber laser marking machines do not require consumables like ink or cartridges. The machines are usually air-cooled and require minimal maintenance, making them cost-effective and environmentally friendly. They have a long operational life, often exceeding 100,000 hours.
Customizable and Adaptable: The machines can be customized to fit various production needs. They offer adjustable laser power options (e.g., 20W, 30W, 50W) and marking areas (e.g., 110mm x 110mm). The flexibility of these machines allows them to be used across different industries for diverse applications such as marking dates on food packaging, serial numbers on electronic components, or batch codes on pharmaceutical products.
Real-Time Monitoring and Automation: Advanced models are equipped with real-time monitoring and automation features. They can integrate with IoT systems, providing live data and alerts for predictive maintenance, thus reducing downtime and increasing efficiency.

Why Choose Kirin Laser's Flying Fiber Laser Marking Machine?

Optimized for Automated Production: The Kirin Laser flying fiber laser marking machine features an integrated design with advanced automation capabilities, such as automatic sensors and rotary encoders, ensuring seamless, fully automated marking operations on the fly. This makes it the ideal solution for high-volume production environments that demand precision and speed.

Versatile and User-Friendly Application: Our machine is designed for easy installation and use, with intuitive software that supports a range of adjustable parameters to accommodate different marking needs. Whether marking serial numbers, barcodes, or detailed graphics, Kirin Laser’s system is adaptable for various applications and industries.

High-Speed Performance: Equipped with a high-speed Galvo head, the Kirin Laser flying fiber laser marking machine achieves remarkable speeds of up to 7000mm/s. This rapid performance allows you to maintain peak productivity, offering swift and accurate marking even in the most demanding production scenarios.

Cost-Efficient with No Consumables: The Kirin Laser machine boasts a robust fiber laser source with a theoretical lifespan of up to 100,000 hours. This durability means there are no consumable costs—no inks, no cartridges—just continuous, reliable operation. This makes it an excellent choice for industries aiming to reduce overhead costs while maintaining high-quality output.

Low Maintenance Requirements: The air-cooled system of Kirin Laser’s flying fiber laser marking machine ensures that the unit is virtually maintenance-free. Designed for long-term, uninterrupted use, this machine reduces the need for frequent checks or repairs, allowing your operations to run smoothly with minimal downtime.

Comprehensive Marking Capabilities: Capable of marking a diverse range of content, the Kirin Laser machine can handle English characters, serial numbers, dates, barcodes, QR codes, logos, and more. It’s a complete solution for any business needing versatile marking capabilities on various materials.

Competitive Pricing: The price of Kirin Laser’s flying fiber laser marking machine ranges from USD 4000 to 7000, depending on your specific needs, business size, and the intended applications. This range offers great flexibility and ensures that you receive the best value for your investment. For a tailored quote and to learn more about how our machines can benefit your business, reach out to our team.

Expert Guidance and Support: Our team of seasoned technical and commercial experts is ready to assist you in choosing the most suitable laser machine to match your operational needs. We provide comprehensive support to ensure you get the most out of your investment in Kirin Laser technology.

If you’re looking to enhance your production capabilities with a reliable, efficient, and cost-effective laser marking solution, Kirin Laser’s flying fiber laser marking machines are the perfect choice. Contact us today for more details and a customized quote!

Send A Enquiry

Frequently Asked Questions

What is the packaging of the product? Is it safe?

At Kirin Laser, we ensure the utmost safety of our flying fiber laser marking machines during transportation with our robust three-layer packaging system:

External Layer: A high-quality plywood case is used for the outer packaging, providing solid protection against external impacts.
Middle Layer: Inside, the machine is surrounded by a thick foam layer to absorb shocks and prevent any potential shaking or movement that could damage the equipment.
Internal Layer: The machine is covered by a thick plastic bag, which is waterproof and safeguards the machine against moisture or other liquid damage.

All potential damage factors have been carefully considered in our packaging process to ensure that the machine reaches you in perfect condition. We work with experienced shipping agents who specialize in secure transportation. To view a sample picture of our packaging, please contact us directly.

What is the delivery time for the laser engraving machine?

The standard production time for a Kirin Laser flying fiber laser marking machine is approximately 5 working days. Once production is complete, the machine is dispatched via air express services like FedEx or TNT. Typically, it takes around 4 to 6 working days for the machine to reach your location, depending on the destination. You can check our customer testimonials to learn more about their experiences with our product delivery.

How to install and run the laser marking machine?

Each laser marking machine is fully installed and tested by our engineers before shipping. For smaller components that may require installation upon arrival, and to help you operate the machine effectively, we provide comprehensive training resources. This includes a detailed training video, a user manual, and other supporting materials. Most of our customers find these resources sufficient to learn the setup and operation of the machine on their own.

How can you get support after purchasing the equipment?

Kirin Laser is committed to providing full support to our customers globally. For machine operation and software guidance, we offer online support in English through various channels like Skype, WhatsApp, WeChat, or email. If remote assistance is required, we can also use TeamViewer software to help you directly on your machine.

For hardware issues, we guide you through a diagnostic process to identify the problematic part, and then we send a replacement part promptly. Whether you are based in China, the USA, or anywhere else, our experienced team will be available to provide timely support and ensure smooth operation of your equipment.

Feel free to contact us at info@kirinlaser.com for any additional questions or to learn more about our laser marking solutions. Our expert team is ready to assist you in selecting the best marking system tailored to your needs.

What is the power consumption of the flying laser marking machine?

The power consumption depends on the laser power. For example, a 30W flying fiber laser marking machine typically consumes around 500-600W, making it energy-efficient for continuous use.

What types of materials can the flying laser marking machine handle?

Flying laser marking machines are versatile and can mark various materials, including metals like stainless steel, aluminum, copper, and non-metals such as plastic, leather, and ceramics.

How does the flying laser marking machine ensure accuracy during high-speed marking?

The machine uses a high-speed galvo scanner system that precisely controls the laser beam's position, ensuring consistent and accurate marking even at high speeds of up to 7000mm/s.

What is the expected lifespan of the laser source in the flying laser marking machine?

The fiber laser source in the flying marking machine typically has a lifespan of up to 100,000 hours, ensuring long-term, reliable performance without the need for frequent replacements.

Can the machine mark on curved or irregular surfaces?

Yes, the flying laser marking machine can mark on slightly curved surfaces. For more complex shapes, special fixtures or attachments may be required to maintain marking quality.

Is it possible to upgrade the software of the laser marking machine?

Yes, the software used in Kirin Laser machines, such as EZCAD, can be regularly updated to include new features and improvements. Updates are provided by the manufacturer.
